Increasing probability of concurrent drought between the water intake and receiving regions of the Hanjiang to Weihe River Water Diversion Project, China

doi:10.1007/s11442-022-2033-2

Abstract

Abstract:

Water diversion projects are an effective measure to mitigate water shortages in water-limited areas. Understanding the risk of such projects increasing concurrent drought between the water intake and receiving regions is essential for sustainable water management. This study calculates concurrent drought probability between the water intake and receiving regions of the Hanjiang to Weihe River Water Diversion Project using Standardized Precipitation Index and Copula functions. Results showed an increasing trend in drought probability across both the water intake and receiving regions from 2.67% and 8.38% to 12.47% and 14.18%, respectively, during 1969-2018. The return period of concurrent drought decreased from 111.11 to 13.05 years, indicating larger risk of simultaneous drought between the two regions. Projections from CMIP6 suggested that under the SSP 2-4.5 and 5-8.5 scenarios, concurrent drought probability would increase by 2.40% and 7.72% in 2019-2050 compared to that in 1969-1990, respectively. Although increases in precipitation during 2019-2050 could potentially alleviate drought conditions relative to those during 1991-2018, high precipitation variability adds to the uncertainty about future concurrent drought. These findings provide a basis for better understanding concurrent drought and its impact on water diversion projects in a changing climate, and facilitate the establishment of adaptation countermeasures to ensure sustainable water availability.

Key words: concurrent drought, climate change, Copula, SPI, Hanjiang to Weihe River Water Diversion Project

WANG Xiaohong, LIU Xianfeng, SUN Gaopeng. Increasing probability of concurrent drought between the water intake and receiving regions of the Hanjiang to Weihe River Water Diversion Project, China[J].Journal of Geographical Sciences, 2022, 32(10): 1998-2012.

Figures/Tables 15

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Table A1

Table A2

Table A3

Table A4

Table A5

Table A6

Table A7

Figure A1

Figure A2

Figure A3

References 85

[1]	Aadhar S, Mishra V, 2020. On the projected decline in droughts over South Asia in CMIP6 multimodel ensemble. Journal of Geophysical Research Atmospheres, 125(20): e2020JD033587.
[2]	AghaKouchak A, Cheng L Y, Mazdiyasni O et al., 2014. Global warming and changes in risk of concurrent climate extremes: Insights from the 2014 California drought. Geophysical Research Letters, 41(24): 8847-8852. doi: 10.1002/2014GL062308
[3]	Amirataee B, Montaseri M, Rezaie H, 2018. Regional analysis and derivation of Copula-based drought Severity-Area-Frequency curve in Lake Urmia basin, Iran. Journal of Environmental Management, 206: 134-144. doi: S0301-4797(17)31005-8 pmid: 29059568
[4]	Bazrafshan J, Nadi M, Ghorbani K, 2015. Comparison of empirical Copula-based Joint Deficit Index (JDI) and multivariate standardized precipitation index (MSPI) for drought monitoring in Iran. Water Resources Management, 29(6): 2027-2044. doi: 10.1007/s11269-015-0926-x
[5]	Chang J X, Li Y Y, Wang Y M et al., 2016. Copula-based drought risk assessment combined with an integrated index in the Wei River Basin, China. Journal of Hydrology, 540: 824-834. doi: 10.1016/j.jhydrol.2016.06.064
[6]	Chang W J, Dong X, Ma H B et al., 2020. Basin water resources carrying capacity and affordable water transfer scale in consideration of water consumption. Journal of Yangtze River Scientific Research Institute, 37(9): 8-12, 17. (in Chinese)
[7]	Chen R Z, Sang Y F, Wang Z G et al., 2013. Influence of rich-poor precipitation on water resource allocation of the Hanjiang-to-Weihe River Water Transfer Project. Resources Science, 35(8): 1577-1583. (in Chinese)
[8]	Chen W, Lan X Q, Wang L et al., 2013. The combined effects of the ENSO and the Arctic Oscillation on the winter climate anomalies in East Asia. Chinese Science Bulletin, 58(12): 1355-1362. doi: 10.1007/s11434-012-5654-5
[9]	China Meteorological Administration (CMA), 1995. Shaanxi has a rare drought this year. Accessed 15 October 2021. http://www.cma.gov.cn/kppd/kppdqxsj/kppdtqqh/201212/t20121214_196461.html.
[10]	Dai A G, 2013. Increasing drought under global warming in observations and models. Nature Climate Change, 3(1): 52-58. doi: 10.1038/nclimate1633
[11]	Dai J Y, Wu S Q, Wu X F et al., 2020. Impacts of a large river-to-lake water diversion project on lacustrine phytoplankton communities. Journal of Hydrology, 587: 124938. doi: 10.1016/j.jhydrol.2020.124938
[12]	de Andrade J G P, Barbosa P S F, Souza L C A et al., 2011. Interbasin water transfers: The Brazilian experience and international case comparisons. Water Resources Management, 25(8): 1915-1934. doi: 10.1007/s11269-011-9781-6
[13]	Deng W J, Song J X, Sun H T et al., 2020. Isolating of climate and land surface contribution to basin runoff variability: A case study from the Weihe River Basin, China. Ecological Engineering, 153: 105904. doi: 10.1016/j.ecoleng.2020.105904
[14]	Di Baldassarre G, Wanders N, AghaKouchak A et al., 2018. Water shortages worsened by reservoir effects. Nature Sustainability, 1(11): 617-622. doi: 10.1038/s41893-018-0159-0
[15]	Du X Z, Bai T, Ma X et al., 2017. Study on water transfer mode of reservoir group within water-transferring region for Hanjiang-to-Weihe River Valley Water Diversion Project. Water Resources and Hydropower Engineering, 48(8): 2-7, 136. (in Chinese)
[16]	Fang W, Huang S Z, Huang G H et al., 2019. Copulas-based risk analysis for inter-seasonal combinations of wet and dry conditions under a changing climate. International Journal of Climatology, 39(4): 2005-2021. doi: 10.1002/joc.5929
[17]	Fu Q, Feng S, 2014. Responses of terrestrial aridity to global warming. Journal of Geophysical Research: Atmospheres, 119(13): 2014JD021608.
[18]	Gebrechorkos S H, Huelsmann S, Bernhofer C, 2020. Analysis of climate variability and droughts in East Africa using high-resolution climate data products. Global and Planetary Change, 186: 103130. doi: 10.1016/j.gloplacha.2020.103130
[19]	Gohari A, Eslamian S, Mirchi A et al., 2013. Water transfer as a solution to water shortage: A fix that can Backfire. Journal of Hydrology, 491: 23-39. doi: 10.1016/j.jhydrol.2013.03.021
[20]	Granier A, Bréda N, Biron P et al., 1999. A lumped water balance model to evaluate duration and intensity of drought constraints in forest stands. Ecological Modelling, 116(2): 269-283. doi: 10.1016/S0304-3800(98)00205-1
[21]	Guo A J, Chang J X, Liu D F et al., 2017. Variations in the precipitation-runoff relationship of the Weihe River Basin. Hydrology Research, 48(1): 295-310. doi: 10.2166/nh.2016.032
[22]	Hao Z C, AghaKouchak A, 2013. Multivariate Standardized Drought Index: A parametric multi-index model. Advances in Water Resources, 57: 12-18. doi: 10.1016/j.advwatres.2013.03.009
[23]	Hu W P, Zhai S J, Zhu Z C et al., 2008. Impacts of the Yangtze River water transfer on the restoration of Lake Taihu. Ecological Engineering, 34(1): 30-49. doi: 10.1016/j.ecoleng.2008.05.018
[24]	Huang X R, Zhao J W, Yang P P, 2015. Wet-dry runoff correlation in western route of South-to-North Water Diversion Project, China. Journal of Mountain Science, 12(3): 592-603. doi: 10.1007/s11629-014-3180-4
[25]	Hubei Provincial Department of Water Resources (HPDWR), 2014. Jingmen Bureau emergency monitoring for the operation of the Yangtze-to-Hanjiang water diversion project. Accessed 15 October 2021. http://slt.hubei.gov.cn/sw/zzjg/jcdt/jmsw/201408/t20140812_3161232.shtml.
[26]	Jin W T, Wang Y M, Bai T et al., 2019. Multi-objective operation and decision making of parallel reservoirs for Hanjiang-to-Weihe water diversion project in dry years. Journal of Hydroelectric Engineering, 38(2): 68-81. (in Chinese)
[27]	Keener V W, Feyereisen G W, Lall U et al., 2010. El-Niño/Southern Oscillation (ENSO) influences on monthly NO₃ load and concentration, stream flow and precipitation in the Little River Watershed, Tifton, Georgia (GA). Journal of Hydrology, 381(3/4): 352-363. doi: 10.1016/j.jhydrol.2009.12.008
[28]	Le P V V, Phan-Van T, Mai K V et al., 2019. Space-time variability of drought over Vietnam. International Journal of Climatology, 39(14): 5437-5451. doi: 10.1002/joc.6164
[29]	Li L C, Yao N, Li Y et al., 2019. Future projections of extreme temperature events in different sub-regions of China. Atmospheric Research, 217: 150-164. doi: 10.1016/j.atmosres.2018.10.019
[30]	Li S Y, Miao L J, Jiang Z H et al., 2020. Projected drought conditions in Northwest China with CMIP 6 models under combined SSPs and RCPs for 2015-2099. Advances in Climate Change Research, 11(3): 210-217. doi: 10.1016/j.accre.2020.09.003
[31]	Li Y P, Acharya K, Yu Z B, 2011. Modeling impacts of Yangtze River water transfer on water ages in Lake Taihu, China. Ecological Engineering, 37(2): 325-334. doi: 10.1016/j.ecoleng.2010.11.024
[32]	Li Z, Chen Y N, Fang G H et al., 2017. Multivariate assessment and attribution of droughts in Central Asia. Scientific Reports, 7: 1316. doi: 10.1038/s41598-017-01473-1 pmid: 28465559
[33]	Liu F, Tang C, Ma T H et al., 2019. Characterizing rockbursts along a structural plane in a tunnel of the Hanjiang-to-Weihe River Diversion Project by microseismic monitoring. Rock Mechanics and Rock Engineering, 52(6): 1835-1856. doi: 10.1007/s00603-018-1649-0
[34]	Liu H, Yin J, Feng L, 2018. The dynamic changes in the storage of the Danjiangkou Reservoir and the influence of the South-North Water Transfer Project. Scientific Reports, 8: 8710. doi: 10.1038/s41598-018-26788-5 pmid: 29880825
[35]	Liu X M, Liu C M, Luo Y Z et al., 2012. Dramatic decrease in streamflow from the headwater source in the central route of China’s water diversion project: Climatic variation or human influence? Journal of Geophysical Research: Atmospheres, 117: D06113.
[36]	Liu X M, Luo Y Z, Yang T T et al., 2015. Investigation of the probability of concurrent drought events between the water source and destination regions of China’s water diversion project. Geophysical Research Letters, 42(20): 8424-8431. doi: 10.1002/2015GL065904
[37]	Liu Z Y, Menzel L, Dong C Y et al., 2016. Temporal dynamics and spatial patterns of drought and the relation to ENSO: A case study in Northwest China. International Journal of Climatology, 36(8): 2886-2898. doi: 10.1002/joc.4526
[38]	Liu Z Y, Zhang X, Fang R H, 2018. Multi-scale linkages of winter drought variability to ENSO and the Arctic Oscillation: A case study in Shaanxi, North China. Atmospheric Research, 200: 117-125. doi: 10.1016/j.atmosres.2017.10.012
[39]	Ma M W, Song S B, Ren L L et al., 2013. Multivariate drought characteristics using trivariate Gaussian and Student t copulas. Hydrological Processes, 27(8): 1175-1190. doi: 10.1002/hyp.8432
[40]	Mao R, Gong D Y, Yang J et al., 2011. Linkage between the Arctic Oscillation and winter extreme precipitation over central-southern China. Climate Research, 50(2): 187-201. doi: 10.3354/cr01041
[41]	Martin E R, 2018. Future projections of global pluvial and drought event characteristics. Geophysical Research Letters, 45(21): 11913-11920.
[42]	Miao L J, Li S Y, Zhang F et al., 2020. Future drought in the dry lands of Asia under the 1.5 and 2.0 °C warming scenarios. Earth’s Future, 8(6): UNSP e2019EF001337.
[43]	Milly P C D, Betancourt J, Falkenmark M et al., 2008. Climate change-stationarity is dead: Whither water management? Science, 319(5863): 573-574. doi: 10.1126/science.1151915 pmid: 18239110
[44]	Ministry of Water Resources of the People’s Republic of China (MWR-PRC), 2016a. The proposal of the second phase project of the Han-to-Wei Water Diversion Project passed the review of the Ministry of Water Resources. Accessed 15 October 2021. http://www.mwr.gov.cn/xw/dfss/201702/t20170212_821844.html.
[45]	Ministry of Water Resources of the People’s Republic of China (MWR-PRC), 2016b. The dam for the Sanhekou Water Control Project of the Han-to-Wei Water Diversion Project has officially started to pour. Accessed 15 October 2021. http://www.mwr.gov.cn/ztpd/2015ztbd/jktjjsgszdslgcjs/jzcx/201611/t20161121_772290.html.
[46]	Morris K S, Bucini G, 2016. California’s drought as opportunity: Redesigning U.S. agriculture for a changing climate. Elementa: Science of the Anthropocene, 4: 1-12. doi: 10.32332/elementary.v4i1.1028
[47]	Nelsen R B, 2006. An Introduction to Copulas. New York: Springer-Verlag, 272pp.
[48]	Noguera I, Domínguez-Castro F, Vicente-Serrano S M, 2020. Characteristics and trends of flash droughts in Spain, 1961-2018. Annals of the New York Academy of Sciences, 1472(1): 155-172.
[49]	Pokhrel Y N, Hanasaki N, Wada Y et al., 2016. Recent progresses in incorporating human land-water management into global land surface models toward their integration into Earth system models. Wiley Interdisciplinary Reviews: Water, 3(4): 548-574.
[50]	Ren K, Huang S Z, Huang Q et al., 2020. Assessing the reliability, resilience and vulnerability of water supply system under multiple uncertain sources. Journal of Cleaner Production, 252: 119806. doi: 10.1016/j.jclepro.2019.119806
[51]	Rogers S, Chen D, Jiang H et al., 2019. An integrated assessment of China’s South-North Water Transfer Project. Geographical Research, 58(1): 49-63. doi: 10.1111/1745-5871.12361
[52]	Salvadori G, De Michele C, 2015. Multivariate real-time assessment of droughts via Copula-based multi-site hazard trajectories and fans. Journal of Hydrology, 526: 101-115. doi: 10.1016/j.jhydrol.2014.11.056
[53]	Salvadori G, De Michele C, Durante F, 2011. On the return period and design in a multivariate framework. Hydrology and Earth System Sciences, 15(11): 3293-3305. doi: 10.5194/hess-15-3293-2011
[54]	Shaanxi Provincial Department of Water Resources (SPDWR), 2020. Reply letter to the 3rd meeting of the 12th Provincial CPPCC No.894. Accessed 15 October 2021. http://slt.shaanxi.gov.cn/zfxxgk/fdzdgknr/jyta/202011/t20201118_2119133.html.
[55]	Shao X J, Wang H, Wang Z Y, 2003. Interbasin transfer projects and their implications: A China case study. International Journal of River Basin Management, 1(1): 5-14. doi: 10.1080/15715124.2003.9635187
[56]	She D X, Mishra A K, Xia J et al., 2016. Wet and dry spell analysis using Copulas. International Journal of Climatology, 36(1): 476-491. doi: 10.1002/joc.4369
[57]	She D X, Xia J, Shao Q X et al., 2017. Advanced investigation on the change in the streamflow into the water source of the middle route of China’s water diversion project. Journal of Geophysical Research: Atmospheres, 122(13): 6950-6961.
[58]	Sivakumar V L, Ramalakshmi M, Krishnappa R R et al., 2020. An integration of geospatial technology and standard precipitation index (SPI) for drought vulnerability assessment for a part of Namakkal district, South India. Materials Today: Proceedings, 33: 1206-1211. doi: 10.1016/j.matpr.2020.08.157
[59]	Sonmez F K, Komuscu A U, Erkan A et al., 2005. An analysis of spatial and temporal dimension of drought vulnerability in Turkey using the standardized precipitation index. Natural Hazards, 35(2): 243-264. doi: 10.1007/s11069-004-5704-7
[60]	Stone R, Jia H, 2006. Hydroengineering: Going against the flow. Science, 313(5790): 1034-1037. doi: 10.1126/science.313.5790.1034
[61]	Sun Y, Tian F Q, Yang L et al., 2014. Exploring the spatial variability of contributions from climate variation and change in catchment properties to streamflow decrease in a mesoscale basin by three different methods. Journal of Hydrology, 508: 170-180. doi: 10.1016/j.jhydrol.2013.11.004
[62]	Ukkola A M, De Kauwe M G, Roderick M L et al., 2020. Robust future changes in meteorological drought in CMIP6 Projections despite uncertainty in precipitation. Geophysical Research Letters, 47(11): e2020GL087820.
[63]	Vorosmarty C J, Green P, Salisbury J et al., 2000. Global water resources: Vulnerability from climate change and population growth. Science, 289(5477): 284-288. doi: 10.1126/science.289.5477.284 pmid: 10894773
[64]	Wang J T, 2019. Analysis on spatiotemporal pattern of SPI drought based on meteorological index in North China. Research of Soil and Water Conservation, 26(4): 203-207. (in Chinese)
[65]	Wang T, Tu X J, Singh V P et al., 2021. Global data assessment and analysis of drought characteristics based on CMIP6. Journal of Hydrology, 596: 126091. doi: 10.1016/j.jhydrol.2021.126091
[66]	Wang W, Zhong Y H, Lei X H et al., 2012. Synchronous-asynchronous encounter probability of rich-poor precipitation between water source area and water receiving area of the Hanjiang-to-Weihe River Water Transfer Project. South-to-North Water Diversion and Water Science & Technology, 10(5): 23-26, 36. (in Chinese)
[67]	Wang X Y, Zhou L, Li C et al., 2020. Temporal and spatial evolution trends of drought in northern Shaanxi of China: 1960-2100. Theoretical and Applied Climatology, 139(3/4): 965-979. doi: 10.1007/s00704-019-03024-2
[68]	Wang Z L, Wang J S, Li Y H et al., 2013. Comparison of application between generalized extreme value index and standardized precipitation index in Northwest China. Plateau Meteorology, 32(3): 839-847. (in Chinese) doi: 10.7522/j.issn.1000-0534.2012.00077
[69]	Wen K G, Zhai Y A, 2005. Chinese Meteorological Disasters Dictionary:Shaanxi Volume. Beijing: China Meteorological Press, 211 pp.
[70]	Weng B S, Yan D H, Wang H et al., 2015. Drought assessment in the Dongliao River basin: Traditional approaches vs. generalized drought assessment index based on water resources systems. Natural Hazards and Earth System Sciences, 15(8): 1889-1906.
[71]	Wu B Y, Wang J, 2002. Winter Arctic Oscillation, Siberian High and East Asian winter monsoon. Geophysical Research Letters, 29(19): 1897.
[72]	Yu F L, Zhai S Y, Wang Z et al., 2018. Spatial and temporal variation characteristics of drought during rice growth based on SPI in Southwest China from 1960 to 2012. Scientia Geographica Sinica, 38(5): 808-817. (in Chinese) doi: 10.13249/j.cnki.sgs.2018.05.019
[73]	Yuan X F, Jian J S, Jiang G, 2016. Spatiotemporal variation of precipitation regime in China from 1961 to 2014 from the standardized precipitation index. ISPRS International Journal of Geo-Information, 5(11): 194. doi: 10.3390/ijgi5110194
[74]	Yuan Z, Xu J J, Huo J J et al., 2017. Drought-waterlog encounter probability research between the diversion region and benefited region in the Middle Route of South-to-North Water Transfer Project. IOP Conference Series. Earth and Environmental Science, 82: 012044.
[75]	Zhang C, Duan Q Y, Yeh P J F et al., 2020. The effectiveness of the South-to-North Water Diversion Middle Route Project on water delivery and groundwater recovery in North China Plain. Water Resources Research, 56(10): e2019WR026759.
[76]	Zhang D, Chen P, Zhang Q et al., 2017. Copula-based probability of concurrent hydrological drought in the Poyang lake-catchment-river system (China) from 1960 to 2013. Journal of Hydrology, 553: 773-784. doi: 10.1016/j.jhydrol.2017.08.046
[77]	Zhang D D, Yan D H, Lu F et al., 2015. Copula-based risk assessment of drought in Yunnan province, China. Natural Hazards, 75(3): 2199-2220. doi: 10.1007/s11069-014-1419-6
[78]	Zhang R, Chen Z Y, Xu L J et al., 2019. Meteorological drought forecasting based on a statistical model with machine learning techniques in Shaanxi province, China. Science of The Total Environment, 665: 338-346. doi: 10.1016/j.scitotenv.2019.01.431
[79]	Zhang R B, Shang H M, Yu S L et al., 2017. Tree-ring-based precipitation reconstruction in southern Kazakhstan, reveals drought variability since A.D. 1770. International Journal of Climatology, 37(2): 741-750.
[80]	Zhao J, Shi S J, Li H E, 2010. Preliminary study on optimizing method of scheme in inter-basin water transfer project. Agricultural Research in the Arid Areas, 28(2): 214-218, 248. (in Chinese)
[81]	Zhao P P, Lu H S, Yang H C et al., 2019. Impacts of climate change on hydrological droughts at basin scale: A case study of the Weihe River Basin, China. Quaternary International, 513: 37-46. doi: 10.1016/j.quaint.2019.02.022
[82]	Zhou T J, Chen Z M, Zou L W et al., 2020. Development of climate and earth system models in China: Past achievements and new CMIP6 results. Journal of Meteorological Research, 34(1): 1-19. doi: 10.1007/s13351-020-9164-0
[83]	Zhou Y L, Guo S L, Hong X J et al., 2017. Systematic impact assessment on inter-basin water transfer projects of the Hanjiang River Basin in China. Journal of Hydrology, 553: 584-595. doi: 10.1016/j.jhydrol.2017.08.039
[84]	Zhu Y L, Liu Y, Wang H J et al., 2019. Changes in the interannual summer drought variation along with the regime shift over Northwest China in the Late 1980s. Journal of Geophysical Research: Atmospheres, 124(6): 2868-2881. doi: 10.1029/2018JD029671
[85]	Zuo D D, Hou W, Wu H et al., 2021. Feasibility of calculating standardized precipitation index with short-term precipitation data in China. Atmosphere, 12(5): 603. doi: 10.3390/atmos12050603

Name of the Subproject	Location	Water storage (10⁶ m³)	Maximum height (m)	Designed discharge (m³/s)	Function
Huangjinxia Water Control Project	Upper Hanjiang, 62 km from Yang County	229	68	70	Water supply, power generation and improvement of navigation conditions
Sanhekou Water Control Project	2 km from the junction of Jiaoxi River, Pu River and Wenshui River	710	145	50	Regulating and storing water
Qinling water conveyance tunnel	Connect the Sanhekou Water Control Project and the Huangchi River in Zhouzhi County	/	/	70	Transport water

Name	ID	Longitude	Latitude	Elevation (m)
Changwu	53929	35°12'N	107°48'E	1206.5
Tongchuan	53947	35°05'N	109°04'E	978.9
Baoji	57016	34°21'N	107°08'E	612.4
Fengxiang	57025	34°31'N	107°23'E	781.1
Yaoxian	57037	34°56'N	108°59'E	710.0
Huashan	57046	34°29'N	110°05'E	2064.9
Lueyang	57106	33°19'N	106°09'E	794.2
Hanzhong	57127	33°04'N	107°02'E	509.5
Foping	57134	33°31'N	107°59'E	827.2
Shangzhou	57143	33°52'N	109°58'E	742.2
Zhenan	57144	33°26'N	109°09'E	693.7
Shiquan	57232	33°03'N	108°16'E	484.9
Wugong	57234	34°15'N	108°13'E	447.8
Ankang	57245	32°43'N	109°02'E	290.8

Model abbreviation	Institute ID	Horizontal resolution (°lon × °lat)	Ensembles variables		Study area
Model abbreviation	Institute ID	Horizontal resolution (°lon × °lat)	Ensembles variables		Water intake	Water receiving
BCC-CSM2-MR	BCC	1.125, 1.125 (gn)	r1i1p1f1	pr	0.5938	0.5388
BCC-CSM2-MR	BCC	1.125, 1.125 (gn)	r1i1p1f1	ta	0.9732	0.9738
CNRM-CM6-1	CNRM-CERFACS	1.406, 1.406 (gr)	r1i1p1f1	pr	0.4633	0.4126
FGOALS-f3-L	LASG-CESS	1.25, 1 (gr)	r1i1p1f1	pr	0.5778	0.5135
GFDL-ESM4	NOAA GFDL	1.25, 1 (gr1)	r1i1p1f1	pr	0.5447	0.5310
MIROC6	MIROC	1.406, 1.406 (gn)	r1i1p1f1	pr	0.5403	0.4820
MRI-ESM2-0	MRI	1.125, 1.125 (gn)	r1i1p1f1	pr	0.4598	0.4101
MPI-ESM1-2-LR	MPI-M	1.875, 1.875 (gn)	r1i1p1f1	ta	0.9739	0.9735

Index value	Category
Extreme drought	SPI ≤ ‒2.0
Severe drought	-2.0 < SPI ≤ ‒1.5
Moderate drought	-1.5 < SPI ≤ ‒1.0
Near normal	-1.0 < SPI ≤ 1.0
Moderately wet	1.0 < SPI ≤ 1.5
Very wet	1.5 < SPI ≤ 2.0
Extremely wet	SPI > 2.0

Region	Margin	p value
Water intake	Normal	0.9837
	Logistic	0.9057
	Generalized extreme value	0.9675
	t location-scale	0.9762
	Extreme value	0.3369
Water receiving	Normal	0.9246
	Logistic	0.9627
	Generalized extreme value	0.8944
	t location-scale	0.9389
	Extreme value	0.3159
