The conservation patterns of grassland ecosystem in response to the forage-livestock balance in North China

doi:10.1007/s11442-021-1856-6

Abstract

Abstract:

Being a key ecological security barrier and production base for grassland animal husbandry in China, the balance between grassland forage supply and livestock-carrying pressure in North China directly affects grassland degradation and restoration, thereby impacting grassland ecosystem services. This paper analyzes the spatiotemporal variation in grassland vegetation coverage, forage supply, and the balance between grassland forage supply and livestock-carrying pressure from 2000 to 2015 in North China. We then discuss the spatial pattern of grassland ecological conservation under the impacts of grassland degradation and restoration, and livestock-carrying pressure. Over the last 16 years, the total grassland area in North China decreased by about 16,000 km ², with vegetation coverage degraded by 6.7% of the grasslands but significantly restored by another 5.4% of grasslands. The provisioning of forage by natural grassland mainly increased over time, with an annual growth rate of approximately 0.3 kg/ha, but livestock-carrying pressure also increased continuously. The livestock-carrying pressure index without any supplementary feeding reached as high as 3.8. Apart from the potential livestock-carrying capacity in northeastern Inner Mongolia and the central Tibetan Plateau, most regions in North China are currently overloaded. Considering the actual supplementary feeding during the cold season, the livestock-carrying pressure index is about 3.1, with the livestock-carrying pressure mitigated in central and eastern Inner Mongolia. Assuming full supplementary feeding in the cold season, livestock-carrying pressure index will fall to 1.9, with the livestock-carrying pressure alleviated significantly in Inner Mongolia and on the Tibetan Plateau. Finally, we propose different conservation and development strategies to balance grassland ecological conservation and animal husbandry production in different regions of protected areas, pastoral areas, farming-pastoral ecotone, and farming areas, according to the grassland ecological protection patterns.

Key words: grassland degradation and restoration, forage supply, livestock-carrying pressure, grassland ecosystem conservation, North China

HUANG Lin, NING Jia, ZHU Ping, ZHENG Yuhan, ZHAI Jun. The conservation patterns of grassland ecosystem in response to the forage-livestock balance in North China[J].Journal of Geographical Sciences, 2021, 31(4): 518-534.

Figures/Tables 10

Table 1

Classification types of grassland degradation and restoration according to changes in vegetation coverage in North China"

Grassland types	Vegetation coverage change	Degradation and restoration types	Grassland types	Vegetation coverage change	Degradation and restoration types
Temperate grassland	Decreased by 10%‒20%	Slight degradation	Alpine grassland	Decreased by 10%‒20%	Slight degradation
	Decreased by 20%‒40%	Moderate degradation		Decreased by 20%‒30%	Moderate degradation
	Decreased by more than 40%	Severe degradation		Decreased by more than 30%	Severe degradation
	Increased by 10%‒20%	Slight restoration		Increased by 10%‒20%	Slight restoration
	Increased by 20%‒40%	Obvious restoration		Increased by 20%‒30%	Obvious restoration
	Increased by more than 40%	Extremely significant improvement		Increased by more than 30%	Extremely significant improvement
Temperate meadow	Decreased by 10%‒20%	Slight degradation	Alpine meadow	Decreased by 10%‒20%	Slight degradation
	Decreased by 20%‒30%	Moderate degradation		Decreased by 20%‒40%	Moderate degradation
	Decreased by more than 30%	Severe degradation		Decreased by more than 40%	Severe degradation
	Increased by 10%‒20%	Slight restoration		Increased by 10%‒20%	Slight restoration
	Increased by 20%‒30%	Obvious restoration		Increased by 20%‒40%	Obvious restoration
	Increased by more than 30%	Extremely significant improvement		Increased by more than 40%	Extremely significant improvement
Temperate desert	Decreased by 5%‒15%	Slight degradation	Alpine desert	Decreased by 5%‒10%	Slight degradation
	Decreased by 15%‒40%	Moderate degradation		Decreased by 10%‒20%	Moderate degradation
	Decreased by more than 40%	Severe degradation		Decreased by more than 20%	Severe degradation
	Increased by 5%‒15%	Slight restoration		Increased by 5%‒10%	Slight restoration
	Increased by 15%‒40%	Obvious restoration		Increased by 10%‒20%	Obvious restoration
	Increased by more than 40%	Extremely significant improvement		Increased by more than 20%	Extremely significant improvement

Table 1

Table 2

Table 3

Figure 1

Table 4

Table 5

Figure 2

Figure 3

Figure 4

Figure 5

References 52

1	Bai Y F, Wu J G, Xing Q et al., 2008. Primary production and rain use efficiency across a precipitation gradient on the Mongolia Plateau. Ecology, 89:2140-2153. doi: 10.1890/07-0992.1
2	Chang H Q, Xu W Y, Yuan J et al., 2012. Current situation of grassland resources and grazing capacity in Ali, Tibet. Pratacultural Science, 29(11):1660-1664. (in Chinese)
3	Chen P F, 2019. Monthly NPP dataset covering China’s terrestrial ecosystems at north of 18°N (1985-2015). Journal of Global Change Data & Discovery, 3(1):34-41. (in Chinese)
4	Cheng J M, Jing Z B, Jing J W et al., 2014. Restoration and utilization mechanism of degraded grassland in the semi-arid region of Loess Plateau. Science in China Series C: Life Science, 44(3):267-279. (in Chinese)
5	Department of Agriculture and Animal Husbandry of Inner Mongolia Autonomous Region, 2018. Grassland Monitoring Report of Inner Mongolia Autonomous Region (GMR-IMAR). (in Chinese)
6	Dong S K, Wu X Y, Liu S L et al., 2015. Estimation of ecological carrying capacity for wild yak, kiang, and Tibetan antelope based on habitat suitability in the Aerjin Mountain Nature Reserve, China. Acta Ecologica Sinica, 35(23):7598-7607. (in Chinese)
7	Du J Z, Wang G X, Li Y S et al., 2015. Rate and causes of degradation of alpine grassland in the source regions of the Yangtze and Yellow rivers during the last 45 years. Acta Prataculturae Sinica, 24(6):5-15. (in Chinese)
8	Fan J W, Shao Q Q, Liu J Y et al., 2010a. Assessment of effects of climate change and grazing activity on grassland yield in the three rivers headwaters region of Qinghai-Tibet Plateau, China. Environmental Monitoring and Assessment, 170(1-4):571-584. doi: 10.1007/s10661-009-1258-1
9	Fan J W, Shao Q Q, Liu J Y et al., 2010b. Dynamic changes of grassland yield in Three River Headwater Region from 1988 to 2005. Acta Agrectir Sinica, 18(1):5-10. (in Chinese)
10	Fan J W, Shao Q Q, Wang J B et al., 2011. An analysis of temporal-spatial dynamics of grazing pressure on grassland in Three Rivers Headwater Region. Chinese Journal of Grassland, 33(3):64-72. (in Chinese)
11	Fang J Y, Piao S L, Zhou L M et al., 2005. Precipitation patterns alter growth of temperate vegetation. Geophysical Research Letters, 32:L21411, doi: 10.1029/2005GL024231. doi: 10.1029/2005GL024231
12	Feng R Z, Zhou W H, Long R J et al., 2010. Characteristics of soil physical, chemical and biological properties on degraded alpine meadows in the headwater areas of the Yangtze and Yellow rivers, Qinghai-Tibetan Plateau. Chinese Journal of Soil Science, 41(2):263-269. (in Chinese)
13	Gao Q Z, Li Y E, Lin E D et al., 2005. Temporal and spatial distribution of grassland degradation in Northern Tibet. Acta Geographica Sinica, 60(6):965-973. (in Chinese)
14	Hu L, Wang C T, Wang G X et al., 2014. Changes in the activities of soil enzymes and microbial community structure at different degradation successional stages of alpine meadows in the headwater region of Three Rivers, China. Acta Agrectir Sinica, 23(3):8-19. (in Chinese)
15	Huang L, Xu X, Shao Q et al., 2014. Improving carbon mitigation potential through grassland ecosystem restoration under climatic change in Northeastern Tibetan Plateau. Advances in Meteorology, 2014: 1-11.
16	Huang L, Xiao T, Zhao Z et al., 2013. Effects of grassland restoration programs on ecosystems in arid and semiarid China. Journal of Environmental Management, 117:268-275. doi: 10.1016/j.jenvman.2012.12.040 pmid: 23391757
17	Huang F X, Gao Q, Zhao S Y, 2000. The concept of carrying capacity on ecological angle of view. Acta Prataculturae Sinica, 9(3):48-57. (in Chinese)
18	Li G, Sun W L, Zhang H et al., 2014. Balance between actual number of livestock and livestock carrying capacity of grassland after added forage of straw based on remote sensing in Tibetan Plateau. Transactions of the Chinese Society of Agricultural Engineering, 30(17):200-211. (in Chinese)
19	Li X Y, Dong S K, Zhu L et al., 2010. Net carbon dioxide exchange of plant communities on degraded and restored alpine grasslands in headwater area of Three Rivers in China. Chinese Journal of Ecology, 29(10):1944-1949. (in Chinese)
20	Li Y P, Ji J J, 2004. Assessment of the productivity and livestock carrying capacity of Inner Mongolia grassland by regional scale modeling. Journal of Natural Resources, 19(5):610-616. (in Chinese)
21	Li Y Y, Dong S K, Li X Y et al., 2012. Effect of grassland enclosure on vegetation composition and production in Headwater of Yellow River. Acta Agrectir Sinica, 20(2):275-279. (in Chinese)
22	Liao S B, Qin Y C, 2014. A spatialization method for survey data of theoretical stock-carrying capacity of grassland in China and its application. Geographical Research, 33(1):179-190. (in Chinese)
23	Liu H L, Lu W H, Chen C, 2011. Research progress of grassland degraded succession and diagnosis. Acta Agrectir Sinica, 19(5):865-871. (in Chinese)
24	Liu H L, Zhu J Z, Jin G L et al., 2009. Characteristic analysis of Seriphidium transillense Poljak. desert grasslands at different degraded stages in the Northern Tianshan Mountains. Acta Agrectir Sinica, 17(4):419-427. (in Chinese)
25	Liu J Y, Ning J, Kuang W H et al., 2018. Spatio-temporal patterns and characteristics of land-use change in China during 2010-2015. Acta Geographica Sinica, 73(5):789-802. (in Chinese)
26	Liu J Y, Xu X L, Shao Q Q, 2008. The spatial and temporal characteristics of grassland degradation in the Three- River Headwaters Region in Qinghai Province. Acta Geographica Sinica, 63(4):364-376. (in Chinese)
27	Ma A N, Yu G R, He N P et al., 2014. Above and below ground biomass relationships in China’s grassland vegetation. Quaternary Sciences, 34(4):769-776. (in Chinese)
28	Ma W, He J S, Yang Y et al., 2010. Environmental factors covary with plant diversity-productivity relationships among Chinese grassland sites. Global Ecology and Biogeography, 19(2):233-243. doi: 10.1111/j.1466-8238.2009.00508.x
29	Ma W H, Yang Y H, He J S et al., 2008. Above- and belowground biomass in relation to environmental factors in temperate grasslands, Inner Mongolia. Science in China Series C: Life Science, 38(1):84-92. (in Chinese)
30	Ma Y S, Zhou H K, Shao X Q et al., 2016. Recovery techniques and demonstration of degraded alpine ecosystems in the source region of three rivers. Acta Ecologica Sinica, 36(22):7078-7082. (in Chinese)
31	Qian S, Mao L X, Hou Y Y et al., 2007. Livestock carrying capacity and balance between carrying capacity of grassland with added forage and actual livestock in the Qinghai-Tibet Plateau. Journal of Natural Resources, 22(3):389-397. (in Chinese)
32	Shan G L, Xu S M, Chen G et al., 2012. Influence of seasonal exclosure on vegetation restoration in typical steppe, Inner Mongolia. Acta Agrectir Sinica, 20(5):812-818. (in Chinese)
33	Shang Z H, Ding L L, Long R J et al., 2007. Relationship between soil microorganisms, above-ground vegetation, and soil environment of degraded alpine meadows in the headwater areas of the Yangtze and Yellow rivers, Qinghai-Tibetan Plateau. Acta Prataculturae Sinica, 16(1):34-40. (in Chinese)
34	Shen H H, Zhu Y K, Zhao X et al., 2016. Analysis of current grassland resources in China. Chinese Science Bulletin, 61(2):139-154. (in Chinese)
35	Sun L, Wang X T, Wei X H et al., 2012. Effects of restoration measures on vegetation features of alpine degraded grassland of Amdo County in Tibet. Acta Agrectir Sinica, 20(4):616-620. (in Chinese)
36	Wang W Y, Wang Q J, 2001. The structure and plant species diversity of the degraded ecosystems in alpine Kobresia meadow. Acta Prataculturae Sinica, 10(3):8-14. (in Chinese)
37	Wang Y F, Wang S P, 1999. Influence of different stocking rates on belowground biomass in Inner Mongolia steppe. Acta Agrectir Sinica, 7(3):198-203. (in Chinese)
38	Wen J, Zhou H K, Yao B Q et al., 2014. Characteristics of soil respiration in different degraded alpine grassland in the source region of Three-River. Chinese Journal of Plant Ecology, 38(2):209-218. (in Chinese) doi: 10.3724/SP.J.1258.2014.00018
39	Wu X, Li H X, Fu B J et al., 2013. Study on soil characteristics of alpine grassland in different degradation levels in headwater regions of Three Rivers in China. Chinese Journal of Grassland, 35(3):77-84. (in Chinese)
40	Xiao J Y, Pu X P, Xu C L, 2015. Effects of grazing prohibition on restoration of degraded grassland. Pratacultural Science, 32(1):138-145. (in Chinese)
41	Xu C, Zhang L B, Du J Q et al., 2013. Impact of alpine meadow degradation on soil water conservation in the source region of three rivers. Acta Ecologica Sinica, 33(8):2388-2399. (in Chinese) doi: 10.5846/stxb
42	Xu M Y, 2014. A review of grassland carrying capacity: Perspective and dilemma for research in China on “forage-livestock balance”. Acta Prataculturae Sinica, 23(5):321-329. (in Chinese)
43	Xu X L, Wang L, Li J et al., 2017. Analysis of the grassland restoration trend and degradation situation in the “Three-River Headwaters” region since the implementation of the ecological project. Journal of Geo-Information Science, 19(1):50-58. (in Chinese)
44	Yan Y, Alatengtuya , Hu Y F et al., 2011. The tendency and its spatial pattern of grassland changes in the east Xilin Gol from 1975 to 2009. Journal of Geo-Information Science, 13(4):549-555. (in Chinese) doi: 10.3724/SP.J.1047.2011.00549
45	Yang F, Qian Y R, Li J L et al., 2011. Degradation characteristics and causes of desert grassland in the northern Tianshan Mountains. Journal of Natural Resources, 26(8):1306-1314. (in Chinese)
46	Yang F, Shao Q Q, Guo X J et al., 2018. Effects of wild large herbivore populations on the grassland-livestock balance in Maduo County. Acta Prataculturae Sinica, 27(7):1-13. (in Chinese)
47	Yang Z L, Yang G H, 2000. Potential productivity and livestock carrying capacity of high-frigid grassland in China. Resource Science, 22(4):72-77. (in Chinese)
48	Zhang F W, Wang J B, Li Y K et al., 2016. Response of ecosystem photosynthesis and respiration to degradation gradients in an alpine Kobresia Meadow. Chinese Journal of Grassland, 38(1):34-40. (in Chinese)
49	Zhang L X, Fan J W, Shao Q Q et al., 2014. Changes in grassland yield and grazing pressure in the Three Rivers headwater region before and after the implementation of the eco-restoration project. Acta Prataculturae Sinica, 23(5):116-123. (in Chinese)
50	Zhang Y X, Fan J W, Zhang H Y et al., 2018. A method for calculating the suitable monthly carrying capacity of seasonal pasture: Taking Heriheng Village, Henan County, Qinghai Province as example. Pratacultural Science, 35(5):1308-1314. (in Chinese)
51	Zhou H K, Yao B Q, Yu L, 2016. Degradation Succession and Ecological Restoration of Alpine Grassland in the Sanjiangyuan Area. Beijing: Science Press. (in Chinese)
52	Zhou H K, Zhao X Q, Zhou L et al., 2005. A study on correlations between vegetation degradation and soil degradation in the Alpine Meadow of the Qinghai-Tibetan Plateau. Acta Prataculturae Sinica, 14(3):31-40. (in Chinese)

Grassland cover changes	Region	Forest	Cropland	Wetland	Desert	Others
From other ecosystems converted to grassland	Tibet	12.16	0.66	3.23	1.81	0
	Xinjiang	221.43	562.63	755.57	706.52	7.41
	Inner Mongolia	693.09	1733.76	682.47	3668.45	63.07
	Qinghai	20.78	77.02	16.35	304.43	2.14
	Gansu	75.79	891.26	56.38	400.42	4.95
	Total	1023.25	3265.33	1514	5081.63	77.57
From grassland converted to other ecosystems	Tibet	2.67	7.8	615.29	226.4	49.29
	Xinjiang	115.44	11459.14	733.74	190.90	545.71
	Inner Mongolia	1816.39	2924.24	633.75	3122.95	1840.80
	Qinghai	5.63	149.51	429.12	842.29	245.63
	Gansu	380.03	627.20	47.68	138.77	163.94
	Total	2320.16	15167.89	2459.58	4521.31	2845.37

Grassland types	North China			Tibet
Grassland types	Mean (%)	Mean change (%)	Annual trend (%/a)	Mean (%)	Mean change (%)	Annual trend (%/a)
Alpine grassland	18.97	0.11	0.01	15.38	-0.21	-0.06
Alpine meadow	53.35	-0.32	-0.06	45.86	-0.58	-0.13
Alpine desert	7.68	0.34	0.06	6.34	0.29	0.05
Temperate grassland	43.62	1.59	0.28	36.78	-1.16	-0.24
Temperate meadow	75.88	-0.99	-0.19	67.58	-1.31	-0.23
Temperate desert	9.41	0.52	0.10	6.03	-0.34	-0.06
Total	9.40	0.53	0.10	28.50	-0.37	-0.09
Grassland types	Inner Mongolia			Xinjiang
Grassland types	Mean (%)	Mean change (%)	Annual trend (%/a)	Mean (%)	Mean change (%)	Annual trend (%/a)
Alpine grassland	14.69	0.35	0.11	25.77	-0.09	-0.04
Alpine meadow	53.27	1.74	0.35	51.60	-0.76	-0.17
Alpine desert	-	-	-	5.41	0.38	0.07
Temperate grassland	45.03	2.13	0.36	43.71	-1.19	-0.22
Temperate meadow	85.27	0.54	0.07	76.41	-2.82	-0.55
Temperate desert	4.68	0.21	0.05	13.70	0.67	0.13
Total	29.41	1.33	0.23	28.17	-0.11	-0.02
Grassland types	Gansu			Qinghai
Grassland types	Mean (%)	Mean change (%)	Annual trend (%/a)	Mean (%)	Mean change (%)	Annual trend (%/a)
Alpine grassland	17.05	1.19	0.24	29.45	1.14	0.24
Alpine meadow	75.32	-0.05	0.00	59.85	0.01	0.01
Alpine desert	16.67	0.93	0.20	16.75	0.49	0.10
Temperate grassland	40.94	3.34	0.67	37.48	2.03	0.42
Temperate meadow	80.17	0.77	0.15	65.60	0.66	0.16
Temperate desert	7.29	0.75	0.13	9.58	0.77	0.16
Total	35.07	1.19	0.23	35.07	1.19	0.23

Types of grassland degradation and restoration	North China		Tibet		Inner Mongolia
Types of grassland degradation and restoration	Area (km²)	Proportion (%)	Area (km²)	Proportion (%)	Area (km²)	Proportion (%)
Severe degradation	444	0.02	302	0.03	47	0.01
Moderate degradation	5820	0.21	3315	0.38	1454	0.18
Slight degradation	177093	6.51	67514	7.65	66023	8.38
Total degradation	183357	6.74	71131	8.06	67524	8.57
Slight restoration	119270	4.38	15625	1.77	32784	4.16
Obvious restoration	21471	0.79	3266	0.37	2080	0.26
Extremely significant improvement	4879	0.18	629	0.07	170	0.02
Total restoration	145620	5.35	19520	2.21	35034	4.45
Types of grassland degradation and restoration	Xinjiang		Gansu		Qinghai
Types of grassland degradation and restoration	Area (km²)	Proportion (%)	Area (km²)	Proportion (%)	Area (km²)	Proportion (%)
Severe degradation	71	0.01	0	0.00	24	0.01
Moderate degradation	703	0.14	94	0.05	254	0.07
Slight degradation	25994	5.07	5426	3.14	12101	3.32
Total degradation	26768	5.22	5520	3.19	12379	3.40
Slight restoration	53245	10.38	11829	6.84	5748	1.58
Obvious restoration	14118	2.75	1595	0.92	404	0.11
Extremely significant improvement	3869	0.75	138	0.08	72	0.02
Total restoration	71232	13.89	13562	7.84	6224	1.71

Grassland types	North China		Tibet		Inner Mongolia
Grassland types	Mean (g/m²)	Annual trend (g/m²·a)	Mean (g/m²)	Annual trend (g/m²·a)	Mean (g/m²)	Annual trend (g/m²·a)
Alpine grassland	20.23	0.13	19.72	0.10	20.52	0.56
Alpine meadow	49.98	0.33	44.04	0.17	48.19	0.79
Alpine desert	15.79	0.13	16.07	0.20	-	-
Temperate grassland	42.75	0.43	36.41	-0.03	44.70	0.54
Temperate meadow	48.20	0.37	61.75	0.16	55.84	0.54
Temperate desert	14.80	0.15	11.33	0.07	12.38	0.14
Total	33.38	0.27	28.37	0.13	37.62	0.43
Grassland types	Xinjiang		Gansu		Qinghai
Grassland types	Mean (g/m²)	Annual trend (g/m²·a)	Mean (g/m²)	Annual trend (g/m²·a)	Mean (g/m²)	Annual trend (g/m²·a)
Alpine grassland	12.04	-0.02	10.82	0.02	28.78	0.43
Alpine meadow	25.41	-0.23	78.97	0.71	57.69	0.57
Alpine desert	9.41	0.11	13.22	-0.18	22.29	-0.24
Temperate grassland	34.06	-0.12	46.92	0.68	43.37	0.80
Temperate meadow	35.43	0.10	63.57	0.68	37.22	0.35
Temperate desert	17.24	0.14	12.93	0.15	16.80	0.22
Total	23.89	0.04	38.13	0.44	45.99	0.50
